Product Specifications
| Part Number: | WF10123 |
| UPC Number: | 765809235229 |
| Style: | Spin-On Fuel Filter |
| Service: | Fuel |
| Type: | Full Flow |
| Media: | Cellulose |
| Height: | 8.75 (222)* |
| Outer Diameter Top: | 4.731 (120)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 90X2 MM |
| Nominal Micron Rating: | 4 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
|
No Gaskets found.. |
|||
Principle Application:
| Principle Application: | Cummins ISX, QSX Engines - has pre-fill cover on threaded end - once filter is pre-filled with fuel on the inlet side, remove the cover before installing |
